Usage
Applicable scope is milk powder, health products, condiments, snack food etc.
Technological Parameters
Model | DJ-VN100 |
Tank Specifications | 502/401/307, height 100-230mm |
Encapsulation Capability | 6-8cans/min |
Residual Oxygen | ≤3% |
Nitrogen Purity | ≥99.9% |
Overall Dimension | 1800*760*1850mm |
Position Height | 850mm |
Machine Weight | 400kg |
Power | 380V/1.5kW |
Compressed Air | air clean 0.5-0.8MPa(≤40)1m³/H |
Main Material | 304 stainless steel |
Feature
1. Vacuum seaming station to evacuate, gasify and seam cans.
2. Seal tightly,effectively protect product quality.
3. The negative pressure inside can is adjustable to remove the persistent ailment of “buckled can”.
4. The gas inside can is effectively replaced,prolonging shelf life.
5. There is a filter before vacuum pump, with compressed air blow back device, the dust taken away from the filter will be collected through a separated channel(Dust collector is optional).
6. PLCtouch screen make it be easy of operation.
7. Conveyor belt for feeding and evacuation of cans.
8. Surface fully stainless steel structure.
9. Famous brand vacuum pump.
10. The shape of can is rounder.
11. The material of can body are tin plate and composite paper.
Company Introduce
♦ Established in 2008.
♦ Shanghai High-tech Enterprise, CE, ISO9001, TUV.
♦ Located in Shanghai, 1 hour to Hongqiao airport.
♦ 15 years experience factory, Our founder has over 20 years experience in pack machine field that we can apply you best project for your require.
♦ 6-8 International machinery exhibitions each year.
♦ Supply OEM/ODM manufacturing.
♦ More than 10000 Square factory, Over 20 engineers striving for Dingjiang, guarantee quality/service.
♦ As both manufacture and trader, we have great quality and price control over products.
♦ Our product have been exported to 40 countries like United States, Canada, Mexico; Australia, New Zealand; Saudi Arabia, Italy, Spain; France, Poland, Israel, Russia, South Korea; Thailand, Indonesia, Malaysia, Philippines etc.
♦ Philosophy of No quality, No future.
1. Can your machine meet our needs well?A: Just send us your product video and pack weight, then we can choose suitable machine for you.
2. Are you factory or trading company?A: We are 15 years factory focus on powder grain pack machine.
3. How can we make sure about the machine quality after we start the order?A: Before delivery, we do FAT and send you the pictures and videos for you to check the quality, Also we prepare you manual, video, all details photos.
4. What is your terms of packing?A: Pack in wooden cartons.
5. What is your terms of payment?A: T/T 40% as deposit, and 60% before delivery. For big order, we accept L/C at sight.
6. How about your delivery time?A: 15 to 45 days after receiving your advance payment. Details depend on your pack machine.
