parameters machine:
1.Wide range of packaging: applicable to liquid sauces of various states and properties;
2.Easy to operate: the use of PLC control, human-machine interface operating system, making the operation intuitive and convenient;
3.Convenient adjustment: replacement of the variety is completed within about ten minutes.
4.Applicable to different types of packaging bags;
5.Perfect prevention system to ensure the yield and not waste bags and materials;
6.The machine packaging parts are made of stainless steel to ensure the hygiene and safety of the materials and meet the GMP standards;
7.High degree of automation: unmanned in the whole process of weighing and packaging, automatic fault alarm occurs;
8.Part of the use of imported engineering plastics, no need to refuel, reduce pollution of materials;
9.Use oil-free vacuum pump to avoid polluting the production environment;
10.Waterproof design can be washed with water to reduce the difficulty of cleaning and improve the service life of the machine.
parameters machine:
|
Technological paramters |
|
|
Machine Material |
304 stainless steel |
|
Pneumatic Components |
SMC,AIRTAC |
|
Vacuum Components |
Vacuum pump(ORION) |
|
Drive mode |
Frequency conversion motor drive |
|
Measurement |
Filling machine,Peristaltic pump,Draw off pump |
|
Operate interface |
Touch screen |
|
Suitable packing material |
Juice, tomato sauce, sauces, pepper sauce, peanut butter, hand sanitizer,detergent, etc. |
|
Bag type |
Stand-up bag,Zipper bag,Four side seal bag,Three side seal bag,Paper bag,Reticule,M type bag etc. |
|
Bag material |
PA/PE,PET/PE,Aluminum film and other heat sealing film |
|
Bag specification |
W:160~300mm L :100~400mm |
|
Work flow |
1.Pouch supply 2.Date print 3.Open the pouch 4.Feeding 5.Feeding 6.Heat seal7.Heal seal 8.Output |
|
Packing speed |
10~40bags/min |
|
Packing accuracy |
The tolerance is≤±1% |
|
Weight |
2000kg |
|
Dimension |
(L*W*H)1695mm*1725mm*1640mm |
|
Drive power supply |
380V 50HZ |
|
Control power supply |
DC24V |
|
Power |
4kw |
|
Air consumption |
≥0.35m3/min(Compressed air is provided by the user) |
We can Supply you best solution. Supply OEM/ODM manufacturing. Help you improve your brand reputation.
